Measuring Parameters

• Temperatures: in °C
• Measuring range: -110°C … +100°C
• Range of analysis: -90°C…+60°C (300/2-SA)
• Resolution: 0.06 °C
• Accuracy: ± 0.1 °C
• Repeatability / Reproducibility: as per standards methods or better

Software Features

New LabLink software able to manage up to 6 analytical heads simultaneously (stand alone)

• User friendly interface
• All analytical parameters recorded
• Customizable analysis parameters and methods
• Customizable results report
• Printable graphs and results
• Self-identification of the typology of the analysers connected

The software includes:

Analysis Menu

• Standard method as per ASTM / IP / ISO / EN / DIN… norms of reference:
  • (internal) with sample pre-heating
  • (external) without sample pre-heating
• Optional methods:
  • T-sample – T-bath (Delta T constant)
  • cooling rate °C / h
  • selectable bath steps
  • fast bath
  • selectable tilt out test temperature
• Audible alarm and displayed messages (at the end of the analysis and in case of errors and/or malfunctions)

Diagnostic Menu

• Direct access to all analog, digital, inputs and outputs
• Selectable value displaying: °C / Volt

Calibration Menu

• Automatic calibration of each temperature probe
• Last calibration date referred to each single probe displayed and relative data printable
• Display of calibration diagram
• Insertion of offset values
• Standard and advanced calibration modes

Data Utilities

• Fields for introduction of operator and product name
• Archive viewer for files recall
• All analysis stored in Excel® compatible format
• Storage capacity for more than 60’000 analysis
• LIMS compatible

Integrated Touch Screen Panel PC

• TFT/LCD 12"
• Resolution 1024 × 768, 16.2 M colours
• 2 USB ports for connection to an external printer and/or external PC
• Storage capacity for more than 60'000 analysis

Test Jar

• Same dimensions and volume as described by the standard test methods
• Product level mark
• Small edge on the top in order to fix the glass cell to the analytical head

Cooling System

Integrated gas CFC free motor compressors:

• Single stage (for temperatures up to -40°C / 1)
• Double stage (for temperatures up to -80°C / 2)

Equipped with an automatic energy power save system. After 15 minutes from the end of the analysis the cooling system goes in stand-by mode.

Safety Devices

• Pressure controller for 1st stage motor compressor
• Pressure controller for 2nd stage motor compressor
• Thermostat for 2nd stage activation
• Thermo-switch for each cooling / heating jacket
• Motor compressors equipped with internal overload devices

Electrical Supply

• 220V ± 15% / 50 to 60 Hz
• 115V ± 15% / 60 Hz

Cord Cable

• 3 conductors flexible cable 2 m (7 feet) length with PVC sheath oil and heat resistant as per CENELEC directives

Ambient Temperature

• Max 32 °C
• H.R. 80%
